440V High Frequency Induction Hardening Machine , Induction Heating Machine HF-80KW

Brand Name : ORD

Model Number : HF-80KW

Certification : CE,SGS,ISO

Place of Origin : CHINA

MOQ : 1SET

Price : USD3920-4650.00

Supply Ability : 200SET/Month Goods in Stock

Delivery Time : 1-2 Work days

Packaging Details : Exported Wooden Box 2PCS 620*290*630MM 400*260*440MM

Name : High Frequency Induction Heating Equipment

Heating Princial : Non-Contact Heating

Model : HF-80KW

Standard : CE, SGS, ISO, Rosh

Using : Quenching, Hardening, Annealing, Brazing, Soldering

Work Voltage : 440V* 3Phase 50-60Hz

Working Way : Auto, Manual

Max Output Power : 80KW

Working Frequency : 30-80KHZ

Input Current : 75A

Duty cycle : 100% (40 degree room temperature)

Control Way : Infineon IGBT

Protection System : Over Current, Over Voltage, Phase Fail, Under Voltage, Over Heat, Water Lack

Contact Now

440V High Frequency Induction Hardening/Heating Machine HF-80KW Induction Heater

Datasheet:

Type HF -80KW
Work power 440V*3Phase 50-60HZ
The range of operating voltage 400-480VAC
Output Actual power 50KW
Input current 75A
Fluctuating frequency 30-80KHZ
Timing (Heat time, Retain time , Cool time) 1-99S
The flow rate of cooling water 0.1-0.3Mpa 20L/Min
Water temperature protection point 40℃
Duty cycle 100% (40degree room temperature)
Weight

Main parts:53Kg

Transformer Parts:50kg

Size

Main parts:675*325*655mm

Transformer Part: 530*300*475mm

Features:

1. Infineon IGBT module and Inverting technologies of third generation been used; Higher reliability and lower maintenance cost.

2. 100% Duty cycle, continuous working is allowed at maximum power output.

3. Energy Saving Up to 20-30% compare with SCR machine.

4. Soft Switch Technology And prefect Protection system ( Over Heat, Over Current, Under Voltage, Over Voltage, Phase Fail, Lack Water) enhance Good Reliability.

5. Non-contact Heating is the biggest Characteristic of the induction heating.

6. Small Size, light weight, it is easy to operate, no need professinal person to work it.

7. High Frequency, high speed heating, good for quenching, hardening, soldering and so on!

8. The temperature is easy to control and realize automatic control. It can ensure the consistency of product quality and aviod hidden dangers caused by human.

9. The machine has isolation transformer, output Voltage is safty voltage lower than 36V. Every safe to operate our machine.

Application:

1. Heat Treatment All Kinds of the Metal, for example, shaft, gear, pipe and so on!

2. Soldering copper and copper fittings, Soldering Copper with Brass plate, Soldering Copper with S.S. Soldering Alum with Alum.

3. Annealing all kinds of the metal, S.S/ Copper / Alum pipe and Plate,Strip Online Annealing

4. Hot Forging for Copper and brass Fittings, Hot Forging for Steel Bar and steel Plate. Hot Forging before Stamp.

5. Melt Gold, Silver, Platium, Stainless Steel, Steel, Iron, Alum, Zinc and all kinds of metal.

Advantage:
1. Fast Delivering, we have goods in our stock, within 1-2 days can ship the goods to you!

2. 23Years Experiences for such field, CE cerficated, High quality and stable performance!

3. 20-30% Energy saving compare with SCR machine!

4. Warranty time: Within 18 months from the date of delivering, 12months from date of receiving.
5. 24hours*7days Online Service, can solve the problem in time.

6. Within warranty all parts are free for customer for Quality problem.

440V High Frequency Induction Hardening Machine , Induction Heating Machine HF-80KW440V High Frequency Induction Hardening Machine , Induction Heating Machine HF-80KW
